OrionStar Luckibot Plus
Benefits
The LuckiBot Plus offers a unique service and promotion experience, equipped with advanced capabilities.
Unique Dynamic Promotion: The robot integrates dynamic promotion through its eye-catching display panel (27" and 10.1" screens connected), displaying advertising resources in synchronized fashion.
High Capacity: It can support a high load capacity of up to 60 kg (15 kg per tray). It also features modular and adaptable trays to meet specific needs.
Ultra-Precise Navigation: It uses Dual SLAM navigation (laser + vision), ensuring smooth and safe movement even in complex environments.
Cutting-Edge Interaction: Equipped with a 6-microphone array for AI voice interaction with 97% voice recognition accuracy. Supports over 30 languages.
Open Platform: Features an open, customizable Android platform, offering enhanced secondary development possibilities.
Continuous Operation: Battery life can reach up to 9 hours of continuous work, with fast and automatic recharging.
Enhanced Stability: Equipped with a multi-arm vehicle suspension system ensuring stable operation on uneven and oily surfaces.
Performances &Interactions
The LuckiBot Plus is designed for efficiency and customer interaction.
• Power supply It is equipped with high-capacity LG batteries (25.6 Ah). When the power drops below 10%, the robot automatically returns to the charger to recharge.
• Computing Power It is equipped with a Qualcomm 8-core processor and a Microchip MCU 32-Bit. This is the Qualcomm Snapdragon 845 processor, one of the most powerful SOC chips in Android, with top-of-the-line performance.
• Voice Interaction It features a circular array of 6 microphones with 360° sound source positioning and an effective range of 5 meters. AI voice recognition accuracy is 97% even in a noisy environment of 75 dB.
• Display The 27-inch Full HD main screen and 10.1-inch touch screen provide multimodal human-machine interaction.
• Secondary Development Based on Android 9 (RobotOS), it facilitates secondary development with an Android SDK. It offers more than 50 server-side API interfaces and 23 open client-side API interfaces. The cost of this additional plug-in-based development can be reduced to 1/10 of the industry standard.• Power supply It is equipped with high-capacity LG batteries (25.6 Ah). When the power drops below 10%, the robot automatically returns to the charger to recharge.
Applications
Hospitality and Hotels Proactive Welcome: Acts as a lobby receptionist, using facial recognition within a range of 0.8 to 1.5 meters to greet and interact.
Offices and Schools Dynamic Promotion: Displays various forms of advertising (images, videos) on its two screens, actively attracting customers by recognizing faces within a 5-meter range.
Hospitals and Shopping Centers Smart Guidance: Identifies voice commands, plans optimal routes, and efficiently guides visitors to desired locations. Transportation Hubs (Stations) and Museums Tour Guide: Guides visitors to corresponding exhibition areas and broadcasts information using a comprehensive map and explanatory content.
Banks and Public Institutions Dynamic Patrol: Uses dynamic patrol advertising to attract attention; allows free definition of patrol routes and periods.
Smart Q&A: Compatible with over 30 languages to meet diverse needs.
Navigation & Detection
The LuckiBot Plus is equipped with industry-leading obstacle avoidance technology.
• Chassis Stability The automatic leveling independent multi-link suspension system allows it to effectively avoid bumps, ensuring stable operation on uneven and oily floors.
• Navigation Technology The navigation system is based on Dual SLAM (LiDAR + Vision fusion).
• Navigation Components It uses an integrated system comprising LiDAR, visual positioning, visual obstacle avoidance, an odometer, and IMU (Inertial Measurement Unit).
• Obstacle Detection It is equipped with an integrated 210° LiDAR and an omnidirectional 3D obstacle prevention sensor. Its integrated RGBD depth camera allows it to detect small obstacles quickly and accurately.
• Accuracy and Safety Positioning accuracy is in the order of centimeters. The robot can detect obstacles and stop with a response time as short as 0.5 seconds.• Chassis Stability The automatic leveling independent multi-link suspension system allows it to effectively avoid bumps, ensuring stable operation on uneven and oily floors.
Technical Specifications
Dimensions (W×D×H) 530×500×1320 mm
Net weight 43 kg
Total load capacity Max. 60 kg Load per shelf 15 kg per tray
Main screen (Advertising) 27" Full HD (1080x1920)
Secondary screen (Interactive) 10.1" touchscreen (1200x1920)
Processor Qualcomm 8-core + Microchip MCU 32-Bit (Snapdragon 845)
Operating system Android 9 (RobotOS)
Battery life (typical) 9 hours (cruising mode)
Charging time Approximately 5 hours (automatic)
Cruising speed (adjustable) 0.5 - 1.2 m/sNavigation system LiDAR + visual positioning + visual obstacle avoidance + odometer + IMU (Dual SLAM)
Connectivity Cloud, Wi-Fi 2.4G/5G, 4G/5G, Bluetooth, OTA update Microphones
6-microphone array (5 m sound range)
Supported languages+30 languages
